High-end new Labgear Visiblewave VW2L is a twin output wideband LNB compatible with Sky Q™. The VW2L has a fitted Mk4 40mm collar bracket with integrated spirit level for attachment to a Sky™ dish. Without clamp the LNB can be attached to a regular satellite dish.
Key Features:
<!doctype html>
High-end new Labgear Visiblewave VW2L is a twin output wideband LNB compatible with Sky Q™. The VW2L has a fitted Mk4 40mm collar bracket with integrated spirit level for attachment to a Sky™ dish. Without clamp the LNB can be attached to a regular satellite dish.
Kuul Media are pleased to introduce Labgear Visiblewave product line. The VW2L LNB is manufactured from durable parts to ensure longevity and has meet EU, CE, RoSH Standards.
| Input Frequency | : | 10.7 ~ 12.75 GHz |
| Output Frequency | : |
Vertical: 290 ~ 2340 MHz Horizontal: 290 ~ 2340 MHz |
| L.O. Frequencies | : | 10.41 GHz |
| L.O. Stability | : | +/-0.5 MHz (max) @ Room Temp. +/-1 MHz (max) @ -40°C ~ +60°C -50dBc/Hz @ 1kHz (max.) |
| L.O. Phase Noise | : | -75dBc/Hz @ 10kHz (max.) -100dBc/Hz @ 100kHz (max.) |
| Noise Figure | : | 0.1 dB (type.) |
| Conversion Gain | : | 50 dB (min) / 60 dB (max) |
| Gain Flatness @ 26MHz | : | +/-0.5dB (typ.) |
| Gain Variation | : | 7dB (max.) @ full band |
| Cross Polar Isolation | : | 25 dB (typ.) |
| Image Rejection | : | 40 dB (min) |
| Current Consumption | : | 0.85W (max.) (70mA @ +12V DC) |
| Power Voltage | : | 9 – 19V DC |
| Connector Type | : | 75 Female F-connector |
| Output Spurious | : | <-60dBm |
| Operating Temp | : | -40’C ~ +60’C |
| RED Compliance | : | EN 303 372-1 |
Labgear Visiblewave VW2L Wideband LNB UK Spec with Fitted MK4 Bracket (Integrated Spirit Level)
